Installation guide P.23

• The Starter Kill will automatically rearm itself after 1 minute (by default) or 3 minutes (if

configured this way) if no door is left opened (if the doors are monitored) and the ignition

is not turned ON.

Active Mode:

To arm the Starter Kill, press the

button on the transmitter.

1. The parking lights will flash once.

2. The LED on the antenna will flash slowly.

To disarm the Starter Kill, press the

button on the transmitter.

1. The parking lights will flash twice.

2. The LED on the antenna will remain OFF.

InstallationprogrammableFeatures

The following features can be programmed according to the needs of the installation and the

requirements of the user:

IgnitionControlledDoorLocks

• Ignition Lock disabled: turns OFF the Ignition Lock feature.

• Ignition Lock enabled: locks all Doors when the key is in the ON position and the user

presses the Brake Pedal. Similarly, when the Ignition key is turned to the OFF position, the

Doors will unlock.

SecureLock

This feature allows the module to control certain OEM factory alarm systems without requiring

the use of other wires for disarming the OEM alarm. (Namely, this feature is designed for OEM

systems that use the factory lock wire to arm the alarm and the unlock wire to disarm it.)

1) Standard Secure Lock disabled: By default, the unit will send a disarm pulse before IGN,

an arm pulse once the car is remote started and an arm pulse 4 sec after it shuts down the

engine.

Note: No lock pulse and unlock pulse is sent at any moment of the remote start sequence.

2) Standard Secure Lock: If this Option is selected,

at remote start, the module will send an

unlock/disarm pulse (disarming the factory Alarm)

before start-up, lock pulse when the

engine is running, and lock/arm pulse 4 seconds after it shuts down the engine.

Note: The unit DOES NOT send an arm pulse while the engine is under remote start.

3) Smart Secure Lock:

a) If the vehicle was previously locked with the remote starter transmitter, at remote start

the module will send an unlock/disarm pulse before start-up, lock pulse when the engine

is running, and lock/arm pulse 4 seconds after it shuts down the engine.

b) If the vehicle is initially unlocked, the unit will not send a lock pulse, arm pulse, unlock

pulse or a disarm pulse at any moment of the remote start sequence.

Note: The unit DOES NOT send an arm pulse while the engine is under remote start.
