P.26 Installation guide

is held down (maximum of 15 seconds). This negative pulse can be configured to activate

certain functionalities such as rolling up the windows.

2) Pressing and holding the

button for more than 3 seconds will unlock all doors and will

send a negative pulse to the unlock wire (Green wire from the 12-pin harness) as long as the

button is held down (maximum of 15 seconds). This negative pulse can be configured to

activate certain functionalities such as rolling down the windows.

Diagnosticsviaparkinglights

Diagnostictableforshutdown.

Parking lights flashes Cause

• Runtime has expired.

• Shutdown by remote.

• Ready mode is activated.

• Failed start.

• Brake shutdown.

• Hood shutdown.

Flash for 30sec

• Panic mode

Flash for 60sec

• Alarm triggered

Diagnostictableforstartfailure.

Parking lights flashes Cause

(Manual transmission only)

• Ready mode is not activated.

• Tach signal is not learned.

1 slow Î 2 quick

• The system is set to valet mode.

(Automatic transmission

only)

• The parking brake is active.

• Yellow loop is connected.

• Brake wire is active

• A tach signal is detected before Ignition.

• Hood wire is active.

Note: The installer can also use the PRG-1000 to diagnose shutdown and remote start failures.

Refer to the PRG-1000 manual guide.
